Speed Measurement Model PCT 049
Sci-tech Speed Measurement Model PCT 049 uses Speed Sensing magnetic pick-up
Transducers
– Motor with speed varying from 0-25000rpm & rotating slotted wheel having 8 slots,
– Individual signal conditioning circuit with programmable threshold comparator.
– F to V Converter with span & zero amplifiers.
Transducer /Sensor
– Magnetic Pick-up Transducer is used.
– Photo Pick up Transducer is also used
Measurement Options
- On-board Digital Panel Meter provided.
- Output available on 2mm Banana sockets for Monitoring
On-board Features
- On-board Instrumentation Amplifier provided.
- Block Description Screen printed on glassy epoxy PCB.
- 6V DC Motor with necessary attachment for measurement is provided
Interconnections
- All interconnections are made using 2mm banana Patch cords.
- Test points are provided to analyse signals at various points.- All ICS are mounted on IC Sockets.
- Bare board Tested Glass Epoxy SMOBC PCB is used.
- In-Built Power Supply of +5V/1.5A, ±12V/250mA with Power ON indication
- Set of 2mm Patch cords for interconnections
- User's Manual with sample experimental programs
