CHARACTERISTICS OF FET, MOSFET, IGBT TRAINER Model ETR 005

Specifications

• Resistance Block consisting of One Resistance of 1K and One Potentiometer of 100K.
• One LED indicator to indicate Power input.
• On-board Semiconductor Devices MOSFET   FET/JFET   IGBT
• Variable DC power supply: 0 to + 15 V/150mA
• Variable DC power supply: 0 to + 30 V/150mA

• Interconnections

• All interconnections are made using 2mm banana Patch cords.
• All ICS are mounted on IC Sockets.
• Bare board Tested Glass Epoxy SMOBC PCB is used.
• High impact plastic enclosures.
• Set of 2mm Patch cords for interconnections.
• User’s Manual with sample experimental programs
