Transistors Flip-Flop Trainer Kit Model ETR 024
‘Sci-tech’ Transistors Flip-Flop Trainer Kit Model ETR 024 is Versatile trainer which is capable of performing the experiments for all the temporal behavior of flip-flops for different input connections for students to get fully accustomed with the semiconductors and their applications.
The Instruction Manual provides list of experiments that shows their applications.
‘Sci-tech’ Transistors Flip-Flop Trainer Kit Model ETR 024 is Versatile trainer which is capable of performing the experiments for all the temporal behavior of flip-flops for different input connections for students to get fully accustomed with the semiconductors and their applications.
The Instruction Manual provides list of experiments that shows their applications.
Technical Specification
- One LED indicator to indicate Power input.
- Three Input Switches
- Two LED Driver
- One Manual Pulser
- Fixed AC power supply: 230 VAC
- All interconnections are made using 2mm banana Patch cords.
- Bare board Tested Glass Epoxy PCB is used.
- Set of 2mm Patch cords for interconnections
- Measurement of signals at the input and output of rocker circuits
- Study of the temporal behavior of flip-flops for different input connections
- Definition of the impact of different input connections on the time behavior of flip-flop circuits
- Study of the switching behavior of flip-flops with respect to pulse or rectangular input signals
- Study of the switching behavior of flip-flops with respect to push-button signals
