Load Measurement Using Strain Gauge (Load Cell) Trainer Model PCT 022
Sci-tech Load Measurement Using Strain Gauge (load Cell) Trainer Model PCT 022
– All interconnections are made using 2mm banana Patch cords.
– Test points are provided to analyse signals at various points.
– All ICS are mounted on IC Sockets.
– Bare board Tested Glass Epoxy SMOBC PCB is used.
– In-Built Power Supply of +5V/1.5A, ±12V/250mA with Power ON indication
– Set of 2mm Patch cords for interconnections
– User’s Manual with sample experimental programs
Transducer
- Resistive Pressure Transducer with transparent enclosure.
- Load in weights can be measured up to 3 KGs.
- Primary Excitation voltage of 12V DC
Measurement Options
- On-board Digital Panel Meter provided
- Output available on 2mm Banana sockets for Monitoring
- Weights can be verified by Physical counting of weights
On-board Features
- Provided with excitation voltage
- Weights of different denominations provided
- Onboard Instrumentation Amplifier provided
- Block Description Screen printed on glassy epoxy PCB
- Facility to Interface with PC (Optional)
- Facility to Interface with 8085/86/51kit(Optional)
