Brushless DC Motor Trainer Model ELTR 006

  • Easy and safe wiring by students due to 4mm sturdy shrouded banana patch cords and shrouded socket arrangement for high voltage circuits.
  • Facilitates easy learning about operative characteristics of BLDC motor.
  • Each panel has ABS molded plastic sturdy enclosure, and colorful screw less overlays showing circuit diagram & its connection tag numbers for easy understanding and connections.
  • Set of Instructor Guide & Student Workbook.
  • Easy and safe wiring by students due to 4mm sturdy shrouded banana patch cords and shrouded socket arrangement for high voltage circuits.
  • Facilitates easy learning about operative characteristics of BLDC motor.
  • Each panel has ABS molded plastic sturdy enclosure, and colorful screw less overlays showing circuit diagram & its connection tag numbers for easy understanding and connections.
  • Set of Instructor Guide & Student Workbook.
TECHNICAL SPECIFICATIONS  Powder coated sturdy Aluminum flat panel (table top) system, carrying various voltage components housed in plastic enclosures (panel).
  • Instrumentation Power supply cum Multichannel DPM panel Module 8
  • +5V, 300mA
  • Multi-channel DPM for digital display for speed
  BLDC-1 panel
  • 24VDC/3A (8A optional) power supply for BLDC motor]
  • Speed display DPM
  BLDC-2 panel
  • BLDC controller circuit.
  • BLDC motor
  • Tacho output.
  BLDC-3 panel
  • Forward/reverse switch.
  • Brake switch
  •  Test points for PWM outputs
  • Speed control Pot.
  Brush less DC motor
  • Voltage: 24VDC
  • Wattage:200W
  • Max Speed: 2500RPM.
  • Frame: 34, panel  mounted
  • Bidirectional
  • Braking system
  Mechanical specifications
  • Aluminum rack: 4 x 1 matrix used as flat demo panel system to house panels needed for the trainer ordered.
  • Dimensions : 500(H) x 910(L) x 300(D)mm
