Liquid Sedimentation Apparatus Model FM 057
Liquid Sedimentation Apparatus Model FM 057
Sci-tech Liquid Sedimentation Studies Apparatus Model FM 057 is useful in investigation & comparison of sedimentation processes in different suspensions.
Item Description
The trainer is provided with five transparent cylindrical tanks for the purpose. The suspensions are prepared in measuring cups, poured into the removable tanks, and mixed by shaking. The tanks are then mounted vertically on the experimental unit. To aid observation of the sedimentation process, the tanks are illuminated from behind. Detailed Operation & Maintenance Manual is provided along with the trainer.
Features
Includes 5 sedimentation columns for comparison of sedimentation process.
Columns illuminated to aid in observation of sedimentation process.
Technical Specifications
Technical Specifications
Sedimentation Column: Length: 1.000 mm, Diameter: 50 mm, Scale division: 1mm, Material: Glass
Fluorescent tubes
Measuring cups
Stopwatch
Experiment Capabilities
Determination and comparison of the settling velocities of solids in suspensions dependent on the solid density and concentration and the liquid density and viscosity
Influence of flocculent on the settling velocity
Services required
Electric Supply 230 V AC, Single Phase.
Balance, Flocculent
